PVC Surge Block 2" Sch40
- SKU:
- 254443
Pipe Ends 1" Male NPT x 1" Female 8TPI. Johnson open core PVC Surge Blocks are used in well rehabilitation or well development. Standard with Female flush thread on one end and Male NPT on the other. They are constructed of PVC and HDPE and designed to fit the I.D. Schedule 40 PVC pipe.
Surging and Rehab:
This Surge Block can be used in well rehabilitation and cleaning. By capping the end of the PVC pipe connected to the Surge Block, you can plunge the well and force the well water and cleaner into the surrounding formation. In addition, the rigid HDPE flanges help remove any additional scaling on the inside of the casing and screen. After surging, wait the recommended time for well treatment and discharge the well water.
Developing:
The Surge block can assist in developing a well. By connecting a ball valve or check valve above the surge block, you can develop the well through repeated up and down motion of the connected pipe.
Specifications
PVC Size: 2"
Schedule: 40
Connection Pipe Size 1: 1" Male NPT
Connection Pipe Size 2: 1" Female Flush Thread
Material: PVC and HDPE with SS set screws
Check Ball: No
Number of Flanges: 2
-
Description
Pipe Ends 1" Male NPT x 1" Female 8TPI. Johnson open core PVC Surge Blocks are used in well rehabilitation or well development. Standard with Female flush thread on one end and Male NPT on the other. They are constructed of PVC and HDPE and designed to fit the I.D. Schedule 40 PVC pipe. Surging and Rehab:This Surge Block can be used in well rehabilitation and cleaning. By capping the end of the PVC pipe connected to the Surge Block, you can plunge the well and force the well water and cleaner into the surrounding formation. In addition, the rigid HDPE flanges help remove any additional scaling on the inside of the casing and screen. After surging, wait the recommended time for well treatment and discharge the well water. Developing:The Surge block can assist in developing a well. By connecting a ball valve or check valve above the surge block, you can develop the well through repeated up and down motion of the connected pipe. SpecificationsPVC Size: 2"Schedule: 40Connection Pipe Size 1: 1" Male NPTConnection Pipe Size 2: 1" Female Flush ThreadMaterial: PVC and HDPE with SS set screwsCheck Ball: NoNumber of Flanges: 2
-
Data Sheets
Pipe Ends 1" Male NPT x 1" Female 8TPI. Johnson open core PVC Surge Blocks are used in well rehabilitation or well development. Standard with Female flush thread on one end and Male NPT on the other. They are constructed of PVC and HDPE and designed to fit the I.D. Schedule 40 PVC pipe.
Surging and Rehab:
This Surge Block can be used in well rehabilitation and cleaning. By capping the end of the PVC pipe connected to the Surge Block, you can plunge the well and force the well water and cleaner into the surrounding formation. In addition, the rigid HDPE flanges help remove any additional scaling on the inside of the casing and screen. After surging, wait the recommended time for well treatment and discharge the well water.
Developing:
The Surge block can assist in developing a well. By connecting a ball valve or check valve above the surge block, you can develop the well through repeated up and down motion of the connected pipe.
Specifications
PVC Size: 2"
Schedule: 40
Connection Pipe Size 1: 1" Male NPT
Connection Pipe Size 2: 1" Female Flush Thread
Material: PVC and HDPE with SS set screws
Check Ball: No
Number of Flanges: 2
